Baode Brazed selection form of Condenser and Evaporator
Condenser
Power (KW) Condense Temp 35  Condense Temp  40 Condense Temp  50 Condense Temp  60 Flow rate M3/h
Water 25-30 Water 30-35  Water 40-45  Water 50-55
Model Model Model Model
  BL26 BL50C BL95B BL200 BL26 BL50C BL95B BL200 BL26 BL50C BL95B BL200 BL26 BL50C BL95B BL200
2.5 12       12       12       14       0.43
3.8 16       16       18       18       0.60
5.0 18       20       22       22       0.86
7.5 26       28       30       32       1.28
10.0 34       36       40       42       1.71
12.5 42 18     46 18     48 20     52 20     2.14
15.0 48 22     54 22     58 24     62 24     2.58
17.5 56 24     62 24     66 26       28     3.00
20.0 64 26       26       28       32     3.43
22.5   28       30       32       34     3.85
25.0   30       32       36       38     4.28
27.5   34       36       38       42     4.71
30.0   36       38       42       46     5.14
32.5   40       40       44       48     5.57
35.0   42       44       48       52     6.01
37.5   46       48       50       56     6.42
40.0   48       50       54       60 36   6.85
42.5   50       52       58       64 38   7.28
45.0   52       56       60 38     66 42   7.71
47.5   56 36     58 36     64 40       44   8.14
50.0   58 38     60 38       42       46   8.56
62.5     46       48       52       56   10.70
75.0     54       56       60       66   12.86
87.5     62       64       70       76   15.00
100.0     70       74       80       88   17.13
125.0     88       92       100 52     108 56 21.41
150.0     104 54     108 56     118 62     128 66 25.69
175.0     120 62     126 66     138 70     150 78 29.97
200.0     138 70     144 74     156 80       88 34.25
225.0       78       82       90       98 38.52
250.0       88       90       100       108 42.80
Evaporator
Power (KW) Evaporate Temp 2 Evaporate Temp3 Evaporate Temp 5 Evaporate Temp 10 Flow rate    kg/s
Water12-7 Water12-7 Water15-10 Water20-15
Model Model Model Model
  BL26 BL50D BL95A BL200 BL26 BL50D BL95A BL200 BL26 BL50D BL95A BL200 BL26 BL50D BL95A BL200
2.5 16       18       14       14       0.119
3.5 20       22       18       18       0.167
5.0 24       28       24       24       0.238
7.5 34       40       34       32       0.357
10.0 44       52 26     42       40       0.476
12.5 54 26     64 30     52 26     50 24     0.595
15.0 64 30       36     62 30     58 28     0.715
17.5   34       40       34       32     0.835
20.0   38       46       38       36     0.954
22.5   42       50       42       38     1.070
25.0   46       56       44       42     1.189
27.5   50       60 36     50       46     1.308
30.0   56 34     66 38     52 34     50 30   1.428
32.5   60 36       42     58 36     54 32   1.548
35.0   64 40       44     62 38     58 36   1.669
37.5     42       48       40     62 38   1.784
40.0     44       50       44       40   1.903
42.5     46       54       46       42   2.022
45.0     48       56       48       44   2.141
47.5     52       60       50       46   2.260
50.0     54       62       54       48   2.379
62.5     66       78       64       60   2.973
75.0     80       94       76       72   3.571
87.5     94       110 60     88       82   4.166
100.0     108 58     124 68     100 56     96 52 4.757
125.0     134 70     158 82     126 68     118 64 5.946
150.0     162 84     194 100     154 80     144 76 7.136
175.0     190 98       116     184 94     170 88 8.325
200.0     220 112       134     214 106     198 100 9.514
225.0       126       152       122       114 10.700
250.0       140       168       134       128 11.890
